Description
– Fast-moving highly mobile rig
– Able to drill with pipe or coil tubing
– Some of the quickest rig-up and rig-out times
– Can be rigged up & drilling in under 2 hours!
– Can drill 6,000 ft with coil tubing
– Pipe to coil tubing in less than 10 minutes!
– Only 13 Loads, makes for easy transport
– Foremost 85′ Mast, 140,000 LB Maximum Hook Load
– Foremost Hydraulic Drawworks, 95,000 LB Capacity
– Complete inventory available upon request
- Traveling & Rotary Equipment
- (1) Set Web Wilson Type “B” Manual 2 7/8″- 9 5/8″ Rotary Tongs
- (1) Drill Pipe Elevator
- Set Handling Tools – Drill Pipe, Drill Collar Slips, Safety Clamp, Drill Pipe Elevators
- Mast & Substructure
- Foremost Trailer Mounted Raised Substructure; Sliding Trolley BOP Handler w/ (2) Hydraulic Cylinders, Manual Cellar Controls, Standpipe Valve, Steam Manifold, Explosion Proof Lighting, Mounted on 2005 Peerless T/A 24 Wheel Trailer, Tires 11R22.5, Alloy Buds, Air Suspension, w/ Rear Outriggers, Front Leveling Jacks, Hydraulic & Electrical Lines
- Note: Recertification Days Remaining 1,100, Recertification Completion as of October 2014, as per Company
- Foremost 85′ Mast, 140,000 LB Maximum Hook Load w/ (4) Lines, 1″ Drill Line, (2) 3 Stage Mast Raising Cylinders, Chains, Stand Pipe, Hydraulic Piping, Utility Winch, Access Ladder, Lighting, Fall Arrest
- Timberland Hydraulic Drawworks, 140,000 LB Capacity
- Detroit Series 60 Floor Engine
- Hydraulic Power Unit w/ (5) Main Hydraulic Pumps, Hydraulic Reservoir, Thermal Exchanger, Plumbing, Filters
- 16″ Rotary Table, w/ 1,600 LB Torque, 140,000 LB Maximum Load
- Foremost 100 Ton RC 240 Hydraulic Top Drive w/ Integrated Swivel, Integral Traveling Block & Backup Leg
- Stewart & Stevenson Model M100S Injector, 100,000 LB Lifting Capacity, 40,000 LB Snub Capacity
- Hydraulic System & Components – Raising Cylinders, Winches , BOP Handler, Doghouse Raising System, Hoses, Filters, Valves
- Blowout Prevention Equipment
- Model GK Annular Preventer, 9″ x 3,500 psi
- (2) Townsend Model T88 Ram Preventer, 9″ x 3,000 psi
- Control Tech Working Spool, 9″ x 3,000 psi, w/ 2″ Outlets (3”HCR Valve & 3” Kill Line Valves)
- Control Tech Crossover Spool, 7″ x 3,000 psi
- Mud Pump & Drive
- Mastco Pump Shack, Model JBI JF800 Triplex Mud Pump, Detroit Series 60 14.7 Liter 700 Hp Diesel Engine, Tool Shop
