Efficiant Depth Range

25,000′.

Drawworks

National 1320-UE with two 752 engines and 336 Eaton brakes.

Prime Mover

Four Cat 3512C engines with 1325 kW KATO generators rated at 1,800 amps.

SCR System

IEC 4×4 system with four SCR cubicles and four control cubicles.
Motor control center with 150 kVA ligthing transformer.
750 kVA 600/480 V transformer.

Mast

Skytop Brewster with 1,250,000 lb hookload.

Top Drive

Varco TDS-11 AC-driven portable top drive with 90′ rotating mousehole.

Substructure

30′ Superior Derrick Service unit rated at 2,000,000 lb.

Hydraulic Catwalk

Forum Wrangler 3550.

Rig Walker

Veristic Manufacuring hydraulic rig walker with rig leveling system.

Pumps

(3) Gardner Denver PZ-11 triplex pumps rated at 1,600 hp. Each pump comes with two 752 electric motors for a total of 7,500 psi.

Mud System

(3) 1,500 bbl capacity covered steel tanks with desander, desilter, mud cleaner, and gas buster.
(2) Brandt dual linear motion shakers with mud cleaner and vacuum degasser.

Traveling Block

National with 500-ton capacity.

Rotary Table

Continental Emsco 37 1/2″.

BOP System

(1) 13-5/8″ 5,000 lb Hydril GK annular.
(1) 13-5/8″ 10,000 lb Cameron Type U Single.
(1) 13-5/8″ 10,000 lb Cameron Type U Double.
(1) 225 gal Koomey closing system.
(1) 4″ 10,000 lb choke manifold.

BOP Handling System

Wrangler 30-ton.

Drillstring

20,000′ 5″ OD, Grade G 19.50 lb.
(18) 6′ 3/4″ OD with 31′ drill collars.
(6) 5″ OD heavyweight.
(6) 8″ OD with 30′ drill collars.

Camp

(1) 12-man bunkhouse with crew galley.
(1) Driller bunkhouse with galley.
(1) Toolpusher bunkhouse with galley and office.

Other Equipment

20,000 gallon fuel tank.
500 bbl water tank.
Apollo automatic driller.
Totco electronic drilling recorder.
Varco ST-80 iron roughneck.
